Tektronix 5 CMENET

Product Highlights

Ethernet (10/100/1000BASE-T) compliance test solution

Option 5-CMENET/6-CMENET is a standard specific application for Tektronix 5/6 Series MSO Oscilloscopes. This application includes compliance measurements that enable you to achieve new levels of debugging, efficiency, and accuracy. Option 5-CMENET/6 CMENET adds a long list of IEEE 802.3 and ANSI X3.263 specific measurements for different Ethernet standards to the standard jitter, timing, and signal quality measurements in the 5/6 Series MSO oscilloscopes.

• Comprehensive Ethernet PHY test coverage supporting multiple speeds.
• Highly optimized and intuitive user interface for quick test configuration and validation of electrical signals.
• Compliance and margin testing for accurate analysis and improved interoperability.
• Time-domain and frequency-domain measurements made with a single instrument.
• Jitter and timing measurements with and without filters.
• Amplitude and droop testing for transmitter performance.
• Detailed test reports with results, pass/fail info, test margin, and test specific waveform images.
• Configure test parameters and limits for debug and characterization.
• Configure multiple test runs and analyze the results.
• Preview the test mode waveform before running the tests.
• Additional Peak Distortion Vs Phase Offset and Error Values Vs Symbol Number plots for 1000BASE-T distortion tests.
