Keysight 8494A

Product Highlights

• Frequency Range: dc to 4 GHz
• Insertion Loss at 0 dB: 0.6 dB + 0.09 dB/GHz
• Maximum SWR: 1.5
• Repeatability life: 0.03 dB max 5 million cycles per section, typical
• 5 million cycles per section
• Maximum RF Input Power: 1 W (average), 100 W (peak)
• Connector Type: choice of Type-N female, SMA female, APC-7
• Connect in series with 11716A Attenuator Interconnect Kit, Type-N
• Connect in series with 11716C Attenuator Interconnect Kit, SMA
