CorDEX TP3REX

Product Highlights

The TOUGHPIX DIGITHERM is a ruggedized, compact, digital and thermal imaging camera, your go-to tool for fault finding, documentation whether your work is HVAC, building envelope inspections, electrical repair or facility maintenance.

• Explosion Proof
• 5mega pixel visual
• 80×60 pixel thermal
• -10 ->  380C measurement
• Motorised auto focus
• Adaptive thermal blending
• Wifi image transfer
• Removable battery pack
• Ambient Temperature Tamb -10C to  40C
• Image Download High Speed removable memory card with USB (safe area only( & CorDEX Wireless Android App
• ATEX / IECEx Certificate No. ExVeritas 17 ATEX 0277x / IECEx EXV 17.0013X
• ATEX / IECEx Certificate Type EX II 2G / Ex ib op is IIC T4 Gb
• Image Storage 8GB
• Standard Image Capture Resolution 5 Megapixel
• Screen Size 2.8 inches
• Lens & LCD material Armoured Glass
• Weight 380g
• IP 54
• Body Material Anodised aluminium with polymeric materials
• Battery Type Removable & Rechargeable Ex Power Battery, Capacity 1900mAh, Cell Type Lithium Ion
• Sensor 80×60 Pixel Array
• Imaging Adaptive thermal blending for dual mode imaging
• Low Range -10c to  140C with  /-2C or  /-2% accuracy
• High Range -10c to  380C with  /-5C or  /-5% accuracy

Each Unit Includes

• Rechargeable battery
• Charging dock
• Global charger with UK, US, EU and Australian adaptors
• 8Gb removable memory card
• USB memory card reader
• Wrist strap
